Analog Bits and TSMC -

N16 & N12

Analog Bits and TSMC have collaborated very early and worked closely on numerous 16nm process variations including 16FFC. Our early customers were large volume smart-phone designers who adopted portfolio of differentiated low power foundation IP and later AI and datacenter companies adopted our low-power multi-protocol SERDES. When 16FFC models were released we migrated all our IP’s and added more to the portfolio including qualifying our Analog Foundation IP’s in automotive Grade 1 application with lead customers. When the 12FFC process was rolled out we rapidly migrated these IP’s to 12FFC including our low power SERDES.

More Analog Bits IPs

Benefits of this advanced node collaboration

  • High Volume and numerous SoC’s in production in prestigious smart-phones, datacenter/storage, automotive. compute and consumer SoC’s
  • Numerous test-chips and qualification reports
  • Rapidly migrating and maintaining the IP’s in both 16FFC and 12FFC new process rule changes and PDK updates
  • Broadening the portfolio of our foundation analog foundation IP’s and SERDES IP’s

Production proven IP’s in 16 & 12

  • Clocking – Novel Integer/FracN/SSCG PLL, Ref Clock PLL’s for PCIe 3/4/5
  • Sensor – Automotive grade PVT Sensor, POR Macro, Thermal Diode, P Only Sensor
  • IO’s – Differential clock drivers and receivers, Low Noise Crystal Oscillator Pads, Xtal-less RC Oscillators
  • SERDES:
    • Enterprise Class 1-25G SERDES supporting PCIe4/SAS4 application in 16FFC
    • Consumer Class Ultra-low power PCIe Gen3/SATA3 SERDES in both 16FFC and 12FFC
See Our N3E Process Demo
See Our N5 Test Chip Demo
See Our N4 Core Powered Pinless PVT Sensor Demo

Product Datasheets for TSMC - N16 & N12
