Largest Portfolio of Analog Foundation IP in Clocking, Sensor and IO’s
New Differentiated IP’s
N3 Working Test Chips and Early Production Chips
Automotive Grade N5A Test Chip Silicon Proven
New High Accuracy Sensor

Analog Bits and TSMC -

N5 & N5A

Analog Bits has been an early partner of TSMC in N5 process node and continuing in automotive version of TSMC N5A including our new High Accuracy Sensor. The ability to work with TSMC in advanced processes is a tremendous differentiating value that Analog Bits adds to your designs as we have supported numerous designs well before your design start and what you are assured is a proven IP that has been carefully crafted for optimal power, performance and area.

More Analog Bits IPs

Benefits of this advanced node collaboration

  •  Largest Portfolio of Analog Foundation IP in Clocking, Sensor and IO’s
    • New Differentiated IP’s
      • Clocking – Pinless Integer/FracN PLL, 20GHZ C2C PLL, PCIe5 Ref Clock LC PLL
      • Sensors – Power Supply Glitch Detectors, Pinless and Clockless PVT Sensor
      • IO’s – C2C for chiplets, differential clock buffers and Xtal OSC Pads
  • Silicon Proven Analog Foundation IP’s in N5
  • Silicon Proven SERDES PCIe/Ethernet
  • Automotive Grade N5 IP Taped Out

Some new and novelty IP’s we have in N5

  • Clocking – Pinless/core voltage powered PLL, C2C PLL, Ref Clock PLL’s
  • Sensor – High Accuracy Sensor, Pinless/core voltage PVT Sensor, System Power Detector
  • IO’s – C2C IO’s, Differential clock drivers and receivers, Low Noise Crystal Oscillators, etc
  • SERDES – PCIe Gen4/Ethernet SERDES that will be made available for automotive class SoC’s
See Our N5A Process Demo
See Our N3E Process Demo
See Our N5 Test Chip Demo
See Our N4 Core Powered Pinless PVT Sensor Demo

Product Datasheets for TSMC - N5



Select processes and nodes below. Results will display below the selector box. Click to download, or right click to open the datasheet in a new browser tab or window.

You must be logged in to download or view the product datasheets. If you already have an account, please log in here. New users should register an account.

If you are registering as a new user, you’ll receive a confirmation email from Analog Bits that allows you to complete your registration. Please check your email (and your junk mail folder) for the confirmation email. If you don’t receive the confirmation email shortly, please email arthur@analogbits.com for assistance. Thank you!







    • We trust you will find our product datasheets helpful. Please feel free to contact us for your SoC IP needs.

    We look forward to being your N5 IP Partner.
